Processor 800MHz
- VIA C3/ VIA Eden EBGA processor
Chipset
- VIA CN400 North Bridge
- VIA VT8237 South Bridge
System Memory
- 1 DDR266/333/400 DIMM socket
- Up to 1GB memory size
VGA
- Integrated VIA UniChrome Pro AGP graphics with MPEG-2 decoder
/MPEG-4 Accelerator
Expansion Slots
- 1 PCI
Onboard IDE
- 2 X UltraDMA 133/100 Connector
Onboard Serial ATA
- 2 SATA Connectors
Onboard LAN
- VIA VT6103 10/100 Base-T Ethernet PHY
Onboard Audio
- VIA VT1617A 6channel AC' 97 codec
Onboard TV Out
- VIA VT1623 TV Encoder
Onboard 1394
- VIA VT6307S IEEE 1394 Firewire
Back Panel I/O
- 1 PS2 mouse port
- 1 PS2 keyboard port
- 1 RJ-45 LAN port
- 1 Serial port
- 2 USB 2.0 ports
- 1 VGA port
- 1 PCA port (SPDIF or TV out)
- 1 S-video port
- 3 Audio jacks: line-out, line-in and mic-in (Smart 5.1 Support)
Onboard I/O Connectors
- 3 USB connector for 6additional USB 2.0 ports
- 1 1394 connector for 1 1394 port
- 1 Serial port connector for a second com port
- 1 VIP connector
- 1 Front-panel audio connector (Mic-in and Line-out)
- 1 CD audio-in connector
- 1 FIR connector
- 1 CIR connector (Switchable for KB/MS)
- 1 LPT port connector
- 1 Wake-on-LAN connector
- 2 Fan connectors: CPU/Sys FAN
- 1 I2C connector
- 1 LVDS/TTL module connector (Optional)
- 1 +12V power connector
- ATX power connector
BIOS
- Award BIOS
- 4/8Mbit flash memory
System Monitoring & Management
- CPU voltage monitoring
- Wake-on-LAN, Keyboard Power-on, Timer Power-on
- System power management
- AC power failure recovery
Operating Temperature 0~50°C
Operating Humidity 0% ~ 93% (relative humidity, non-condensing)
Form Factor
- Mini-ITX (6 layer)
- 17 cm x 17 cm
Please
login for creating product ratings.
Your rating:
Please tell us your opinion. Rate the product on a scale from 1 to 5. A value of 5 means the best possible rating.
If you want you also can leave a comment.
Your ratings are honored on many ways. Your report will help other customers to better judge about the products. And
you can benefit from reports other customers are giving.
In addition we credit 0.50 EUR for each given rating with comment and 1.00 EUR for each given rating with comment (more than 150 characters)
on your account. The credit will be substracted automatically on your next order !
We reserve us the right to delete given comments (for example on attempts to give comments with senseless content, copying of other comments, inserting of foreign content, abusing the system for financing orders).
"Fair-use-policy" does apply (as of rule of thumb you should give comments for products which you have purchased already. And your credit account only in rare cases will have 2 or even 3 digits). The credit can only be withdrawn by placing an order. It is not possible to get the credit cash or transferred in an other way.
Customer ratings:
![4 von 5 Sternen](http://pca-3.de/carpcimages/CarTFT/img/stars-4-of-5.png)
Average rating, based on 1 ratings
|
Very good mainbord for in car pc or just for media center soluctions. Good processor evan for a 800hz, nice vga card it will play your dvd and vidios very well. The most great it's totaly Fanless you don't need any fan so it's the most silent boad i ever test.
