CPU
|
Intel Core i3, i5, i7 mobile processors
Socket G2 (rPGA988B), Includes CPU Heatsink / fan for <35W processors
|
Chipset / Video
|
Intel HM67 Express Chipset
Intel HD Graphics ( requires compatible CPU with built-in GPU )
|
Memory
|
2 * SODIMMs Sockets for un-buffered dual channel DDR3-1333/1066 up to 16 GB
|
Expansion Slots
|
1 * PCI Express x16 2.0 (by 16-lane) slot
1 * PCI Express Mini Card slot
|
Storage
|
2 * Serial ATA III 6Gb/s & 3 * Serial ATA II 3Gb/s connectors
Support RAID 0,1,5,10
|
Audio
|
VIA VT 1705 6-Channel HD Audio
|
Ethernet LAN
|
Intel 82577LM Gigabit Ethernet LAN
|
LVDS
|
Onboard 24-bit dual channel LVDS connector
|
USB
|
Embedded 2 * USB 3.0 & 8 * USB 2.0/1.1
|
Special Features
|
Supports ACPI S3, CPU Smart FAN, All solid capacitors
Watchdog hardware monitor
|
Rear Panel I / O
|
2 * USB 3.0 & 4 * USB 2.0/1.1 ports
1 * PS/2 KB/mouse combo connector
1 * RJ-45 port
1 * HDMI port & 1 * VGA port & 1 * DVI-D port
1 * Audio port (Line-in, MIC and Line-out)
1 * Coaxial Out & 1 * Optical Out
|
Internal I / O
|
2 * USB 2.0/1.1 headers for 4 USB ports
1 * 24-bit dual channel LVDS header
1 * Serial header ( RS232/422/485 )
1 * GPIO header
1 * Audio header, 1 * Front panel header
1 * 24-pin ATX power connector, 1 * 4-pin 12V ATX power connector
|
BIOS
|
AMI EFI 32MB SMT Flash ROM
|
Certificate
|
CE, FCC, RoHS, EuP
|
Functional
|
ATM, Automation, medical Equipment, Security, Digital Signage, POS, General Application, Gaming Machine, Transportation
|
Temperature
|
Operating within 0~60 centigrade
Storage within -20-85 centigrade
|
Form Factor
|
Mini-ITX Form Factor (170mm x 170mm) |
